ARMOR

The Computational Design Engine for Pipeline Leak Repair

In the high-stakes world of pipeline integrity, aging infrastructure and rising pressures have created a dangerous "Compliance Gap" that threatens global safety. Currently, the industry is trapped in a "Subjective Engineering" crisis where most leak repair designs are born in a "Shadow Environment"-relying heavily on fragmented Excel sheets, manual code lookups, and "Ancient Knowledge." As proven by recent catastrophic industrial failures, a single mathematical error in bolt-tensioning or metallurgical allowance doesn't just delay a project; it turns a repair clamp into a massive liability, costing millions in downtime and environmental risk.

To eliminate this threat, Armor operates as the world’s first dedicated Computational Design Engine. Moving beyond basic calculators, it utilizes instantaneous Numerical Stress Profiling to convert raw field failure data into Code-Certified Manufacturing Blueprints in minutes. Built to act as the ultimate "Digital Signature" of safety, Armor ensures that every pipeline leak repair sleeve produced is backed by verified engineering intelligence-transforming a temporary patch into a permanent, zero-failure asset..

Request Proposal
PipingLab
99.9%
Accuracy
Real-time
Processing
24/7
Support

The Methodology

Instantaneous Numerical Stress Profiling designed for high-velocity engineering environments.

01

Numerical Stress Profiling

Evaluates stress intensity at 1,000+ critical nodes across the repair geometry. Provides a definitive "Safety Factor Profile" that is transparent and audit-ready in minutes.

02

Cross-Code Validation

Simultaneous validation against ASME and international codes. Ensures localized stress concentrations at bolt-lugs and weld-junctions remain within elastic limits.

03

Instantaneous Design Logic

Delivers FEA-level verification without complex 3D meshing overhead. Eliminates the "Single-Point Failure" risk of manual transcription.

04

Zero-Failure Sealing Map

Calculates gasket seating stress and compression ratios. Establishes a verified seal boundary to arrest the leak on the very first bolt-turn.

Pipeline
Reality

Based on True Incidents: When a line is down, every hour of manual design is an hour of lost revenue and environmental risk.

⚠️

Appin Colliery (2022)

Bolt/Lug failure due to uneven tensioning and metallurgical fatigue not calculated for field conditions.

⚠️

INEOS Forties Pipeline (2017)

Design uncertainty delayed repairs, costing the UK economy an estimated $25M+ per day in lost throughput.

⚠️

Silver Eagle Refinery (2009)

Under-designed enclosure failed under high-temperature hydrogen attack, causing a massive explosion.

The ARMOR
Advantage

Build a reputation for Zero-Failure Engineering.

For the OEM

Reduce design overhead by 90% and quote with 100% confidence in mechanical integrity.

For the EPC Contractor

Eliminate "Approval Bottlenecks." Get repair designs approved on the first submission.

For the Consultant

Faster, more consistent verification check that is harder to fake than manual FEA.

The ARMOR Feature Suite

A full-lifecycle design environment engineered to be more than a calculator—it is an engineering shield.

A

Core Computational Engines

Straight-Pipe Axial Solver, Universal Geometry Solver (Elbows/Tees), and Structural Class Solver (Type A vs. B).

B

Advanced Analysis

Multi-Point Stress Scan evaluating 1,000+ nodes and Numerical Safety Factor Profiling with 2D Stress graphs.

C

Intelligence Hub

Dynamic Fluid Ingest mapping 300+ fluids and automated MOC Validation against ASME codes.

D

Mechanical Integrity

Zero-Failure Sealing Map for gasket stress and Bolt-Load & Circle Optimizer for Torque Maps.

E

High-Fidelity Rendering

Proprietary dynamic engine for 2D technical drawing rendering and manufacturing-ready blueprints.

F

Immutable Audit Trail

Centralized encryption for all design history and TPI-Transparent reports linked directly to code clauses.

The "Approval Shield"

How ARMOR neutralizes liability through rigorous computational verification.

Input Field Data

Feed raw field failure data, pipe dimensions, and fluid parameters directly into the ARMOR environment.

1
2

Pseudo-FEA Execution

The engine performs instantaneous multi-axial numerical stress profiling across 1,000+ critical nodes.

Code-Certified Output

Generate a TPI-Transparent Design Dossier with mechanical datasheets and explicit code clause citations.

3

Enterprise
Security

Built for zero-trust environments.

🔐

End-to-End Encryption

AES-256 standards for all data transfers.

🛡️

Data Privacy

Your files are never shared or used for training.

Safe
Payments

Bank-grade security protocols.

💳

PCI-DSS Compliant

Secure tokenization for all transactions.

📜

Transparent Licensing

Clear terms with secure invoice generation.

System Requirements

OS: Windows 10/11 (64-bit)
RAM: 8GB Minimum
Space: 2GB HDD/SSD
CPU: Intel i5 or Higher
Network: Internet Required

Ready to Build a Zero-Failure Future?

Get in touch to see how ARMOR can neutralize liability and accelerate your pipeline integrity workflows.

Request ARMOR Proposal
